Omada Access Point EAP773 BE11000 Ceiling Mount Tri-Band Wi-Fi 7 ACCESS POINT SINGAPORE Repair Replace NEW

TP-Link Omada EAP773 Wi-Fi 7 Access Point Singapore | BE11000 Tri-Band 10GbE Ceiling Mount AP | Repair & Replacement

The TP-Link Omada EAP773 is a high-performance tri-band Wi-Fi 7 ceiling-mount access point designed for offices, schools, hotels, retail, warehouses and commercial networks requiring 6GHz Wi-Fi, multi-gigabit performance and centralized Omada management.

The key upgrade over mainstream dual-band APs is its combination of 2.4GHz + 5GHz + 6GHz, 320MHz channel width, Multi-Link Operation (MLO) and a 10 Gigabit Ethernet uplink. (TP-Link)

Important Singapore model note

TP-Link’s Singapore pages currently show differing regional/version ratings. One Singapore listing describes the EAP773 as BE11000, while the Singapore V1 page identifies it as BE9300. TP-Link’s current datasheet likewise distinguishes US BE11000 from EU BE9300. The actual Singapore-supplied hardware/version should therefore be confirmed before quotation. (TP-Link)

Tri-Band Wi-Fi 7 – 2.4GHz + 5GHz + 6GHz

Unlike dual-band Wi-Fi access points, the EAP773 adds the 6GHz band.

For the BE11000 configuration, TP-Link specifies theoretical rates of:

2.4GHz — up to 574Mbps
5GHz — up to 4,320Mbps
6GHz — up to 5,760Mbps
Combined — approximately 10.7Gbps / BE11000 class (TP-Link)

The Singapore V1 BE9300 configuration instead lists 574 + 2,880 + 5,760Mbps. These are theoretical PHY rates rather than guaranteed Internet or application throughput. (TP-Link)

10GbE – Not Just 1Gbps or 2.5Gbps

A major advantage of the EAP773 is:

1 × 10 Gigabit Ethernet Port

The 10GbE interface provides substantially more wired uplink capacity than conventional 1GbE APs and even 2.5GbE Wi-Fi 7 models. (TP-Link)

For maximum performance, a commercial network can be designed as:

10G INTERNET / CORE NETWORK → 10GbE PoE SWITCH → EAP773 → Wi-Fi 7 CLIENTS

Installing a high-performance Wi-Fi 7 AP while retaining an old 1Gbps switching infrastructure may create an unnecessary wired bottleneck.

802.3bt PoE – Power + 10GbE Data

For full functionality, TP-Link’s Singapore V1 specification lists 802.3bt PoE or 12V/2.5A DC power. (TP-Link)

This enables a professionally installed ceiling AP to receive network connectivity and power through its Ethernet connection.

For the V1 specification, TP-Link lists approximately:

25.94W — 802.3bt, full functionality
23.4W — 802.3at with reduced 6GHz power
10.1W — 802.3af with radios off / restricted operation (TP-Link)

Therefore, do not assume an old PoE switch will operate the EAP773 at full performance. The PoE standard and available power budget should be checked before replacement.

320MHz Wi-Fi 7 Channel Width

Wi-Fi 7 can use up to 320MHz channel width on 6GHz, subject to regional regulations and compatible clients.

Compared with narrower channels, the wider channel provides greater theoretical capacity for high-throughput applications. (TP-Link)

This is particularly useful for applications involving:

Large File Transfers • Cloud Applications • High-Resolution Video • Workstations • Content Creation • High-Speed LAN Access

Actual channel availability depends on Singapore regulatory requirements, firmware and client compatibility.

Multi-Link Operation – MLO

Multi-Link Operation (MLO) is one of Wi-Fi 7’s major technologies.

Instead of a compatible client relying on only one wireless link, MLO allows coordinated use of different bands/channels. This can improve throughput, latency and reliability under appropriate conditions. (TP-Link)

MLO benefits require compatible Wi-Fi 7 clients.

4K-QAM + Multi-RU

The EAP773 also supports advanced Wi-Fi 7 technologies including:

4K-QAM • Multi-RU • OFDMA • MU-MIMO • Beamforming • BSS Coloring (TP-Link)

4K-QAM increases the amount of information that can be carried per symbol when signal conditions are sufficiently good, while Multi-RU can improve utilisation of available wireless spectrum.

380+ Concurrent Clients

TP-Link specifies 380+ concurrent clients, with 128 listed per 2.4GHz, 5GHz and 6GHz radio in the Singapore V1 specification. (TP-Link)

This does not mean 380 users can simultaneously receive maximum Wi-Fi speed.

Real-world capacity depends on:

Application Bandwidth • Internet Speed • Client Capability • RF Environment • Interference • AP Placement • User Density

For high-density environments, professional RF planning and multiple APs remain important.

Up to 140m² Coverage

TP-Link provides an indicative coverage figure of approximately:

140m² / 1,500ft²

under its specified test conditions. (TP-Link)

Actual Singapore office coverage can be reduced by concrete walls, metal cabinets, server racks, glass, fire-rated partitions and neighbouring Wi-Fi networks.

For this reason, AP quantity should be based on site conditions and RF requirements, not floor area alone.

Up to 24 SSIDs

The EAP773 supports up to 24 SSIDs — eight per radio band. (TP-Link)

A commercial deployment can therefore create separate networks such as:

Management Wi-Fi • Staff Wi-Fi • Guest Wi-Fi • IoT Wi-Fi • Security Wi-Fi • Contractor Wi-Fi

When combined with VLANs and properly configured firewall policies, this provides much better network segmentation than using one wireless network for every device.

WPA3 Enterprise Security

The EAP773 supports:

WPA3-Personal / Enterprise
WPA2-Personal / Enterprise
Client Isolation
VLAN
Access Control
MAC Authentication
Rogue AP Detection
Captive Portal (TP-Link)

This makes it suitable for commercial environments requiring more structured wireless security than a basic consumer Wi-Fi router.

Omada Centralized Management

The EAP773 integrates with the TP-Link Omada SDN ecosystem.

Centralized management options include:

Omada Cloud-Based Controller
OC200 Hardware Controller
OC300 Hardware Controller
Omada Software Controller
Omada App (TP-Link)

A multi-site deployment can therefore operate as:

OFFICE ─┐
SHOP ───┼→ OMADA MANAGEMENT → WEB / APP
WAREHOUSE ─┤
BRANCH ─┘

This gives administrators centralized visibility rather than treating each AP as an isolated device.

Note: TP-Link’s EAP773 Singapore page states that direct Omada Cloud-Based Controller service can require a subscription. Do not market every EAP773 cloud-management method as automatically “lifetime free.” (TP-Link)

AI Roaming + Seamless Mobility

With the appropriate Omada controller architecture, the EAP773 supports advanced roaming functions.

For a larger office:

EAP773 #1 → USER MOVES → EAP773 #2 → EAP773 #3

The network can help compatible mobile devices transition between AP coverage areas rather than requiring users to manually reconnect.

TP-Link lists AI roaming among the EAP773’s advanced Omada functions. (TP-Link)

Omada Mesh

The EAP773 also supports Omada Mesh with an appropriate Omada controller. (TP-Link)

Mesh is useful where installing Ethernet to every AP is impractical.

However, for a new commercial Wi-Fi 7 installation, a wired 10GbE backhaul is preferable where practical, especially when customers are purchasing the EAP773 specifically for high throughput.

Auto Channel Selection & Power Adjustment

In multi-AP deployments, interference between neighbouring access points can reduce performance.

TP-Link provides Auto Channel Selection and Power Adjustment with the appropriate controller architecture. The system can optimise channel and transmit-power settings among APs to reduce interference. (TP-Link)

This becomes increasingly useful in:

Large Offices • Schools • Hotels • Retail • High-Density Commercial Sites

Ceiling or Wall Mount

The EAP773 has an ultra-thin commercial design measuring approximately:

220 × 220 × 32.5mm

TP-Link supplies ceiling/wall mounting hardware with the AP. (TP-Link)

This provides a cleaner installation than placing consumer wireless routers on desks, shelves or above false ceilings.

EAP773 for Office Wi-Fi

Modern offices increasingly use:

Wi-Fi 7 Laptops • Smartphones • Cloud Applications • Teams/Zoom • NAS • Wireless Presentation • IoT • High-Speed Internet

The EAP773’s 10GbE uplink and tri-band architecture make it suitable for organisations upgrading from older Wi-Fi 5 or Wi-Fi 6 infrastructure.

EAP773 for Schools & Training Centres

Educational networks can contain large numbers of simultaneously connected notebooks, tablets and mobile devices.

Multiple centrally managed EAP773 APs can provide:

Centralized Configuration • Multiple SSIDs • VLANs • Client Management • WPA3 • Roaming • 6GHz Capacity

Correct AP density should be determined by room layout and expected simultaneous usage.

EAP773 for Hotels & Commercial Buildings

For hospitality and multi-floor commercial sites, Omada enables multiple APs to operate as part of a centrally managed network.

This can be combined with:

Omada Gateway → Managed PoE Switch → Fibre/10GbE Backbone → EAP773 Access Points

to provide a more scalable architecture than deploying unrelated standalone wireless routers.

Wi-Fi Access Point Repair Singapore

A Wi-Fi problem does not automatically mean the EAP itself has failed.

Proper troubleshooting should check:

PoE Power → Ethernet Cable → RJ45 Termination → Network Switch → Router/Gateway → DHCP → VLAN → Controller → Firmware → RF Interference → Access Point Hardware

For an EAP773 specifically, also check whether the existing PoE switch supplies sufficient power for the required operating mode.

Access Point Replacement Singapore

Replacement may be appropriate when an existing access point suffers from:

Frequent Disconnections

Hardware Failure

Obsolete Wi-Fi Standard

Insufficient Client Capacity

Poor Roaming

Slow 1GbE Uplink

No 6GHz Capability

Unsupported Firmware

Replacing an older AP with the EAP773 can provide a major infrastructure upgrade—but the switch, PoE supply, Ethernet cabling and gateway should also be checked to avoid creating new bottlenecks.

TP-Link EAP773 Key Specifications

*Performance and some features depend on environment, clients, controller, firmware and regulatory region. (TP-Link)

EAP723 vs EAP773

*Regional/hardware version applies. (TP-Link)

TP-Link Omada EAP773 Singapore – SGCCTV

The EAP773 is a significant upgrade for businesses moving toward high-performance Wi-Fi 7 infrastructure:

TRI-BAND Wi-Fi 7

2.4GHz + 5GHz + 6GHz

UP TO BE11000 CLASS

10 GIGABIT ETHERNET

320MHz

MLO + 4K-QAM

380+ CLIENT CAPABILITY

OMADA CENTRALIZED MANAGEMENT

MESH + AI ROAMING

Suitable for Office • School • Hotel • Retail • Commercial Building • Warehouse • High-Speed Business Network.

For Wi-Fi troubleshooting, access-point repair, AP replacement, PoE network upgrading and Omada deployment in Singapore:

SGCCTV.com.sg

10 Frequently Asked Questions

1. Is the EAP773 a Wi-Fi 7 access point? Yes. It supports IEEE 802.11be Wi-Fi 7 and operates across 2.4GHz, 5GHz and 6GHz. (TP-Link)

2. Is EAP773 BE11000? TP-Link has BE11000 and BE9300 regional configurations. The current Singapore site contains both presentations across its pages, so confirm the exact hardware/version supplied before quotation. (TP-Link)

3. Does EAP773 support 6GHz? Yes. Unlike the dual-band EAP723, the EAP773 is a tri-band 2.4/5/6GHz AP. (TP-Link)

4. Does it have 10GbE? Yes. The EAP773 has one 10 Gigabit Ethernet interface. (TP-Link)

5. Does EAP773 support 320MHz? Yes, on the 6GHz band where permitted and when compatible clients and regional settings support it. (TP-Link)

6. What PoE switch should be used? For full functionality, the Singapore V1 specification lists 802.3bt PoE. 802.3at can operate with reduced 6GHz power, while 802.3af results in substantially restricted operation. (TP-Link)

7. How many clients can connect? TP-Link specifies 380+ concurrent clients, although practical capacity depends on traffic, RF conditions and client behaviour. (TP-Link)

8. Does EAP773 support Omada centralized management? Yes. It supports Omada hardware, software and cloud-based controller options. (TP-Link)

9. Is EAP773 an Internet router? No. It is a professional wireless access point. A router/gateway and suitable network/PoE infrastructure are normally required.

10. Should an old Wi-Fi AP be repaired or replaced with EAP773? First diagnose the AP, PoE supply, cabling, switch, router, VLAN/controller configuration and RF environment. Where the existing AP is defective or technologically obsolete, EAP773 provides an upgrade path to tri-band Wi-Fi 7, 6GHz and 10GbE.

15 Facebook Hashtags

#TPLink #TPLinkOmada #EAP773 #OmadaEAP773 #WiFi7 #BE11000 #TriBandWiFi #6GHzWiFi #10GbE #WiFi7Singapore #AccessPoint #CeilingAccessPoint #AccessPointRepair #AccessPointReplacement #SGCCTV

EAP773 BE11000 Ceiling Mount Tri-Band Wi-Fi 7 Access Point

Overview

The EAP773 is an Ultra-Thin Enterprise Wi-Fi 7 Access Point designed to deliver BE11000 Tri-Band Wi-Fi 7 speeds with advanced technologies for businesses requiring high-speed, low-latency, and interference-free wireless connectivity. With its elegant ceiling-mount design, 10G PoE++ port, and Omada Cloud SDN support, the EAP773 is an ideal choice for modern enterprise networks in offices, retail spaces, hotels, and educational institutions.

Key Features

• Wi-Fi 7 BE11000 Speeds: 5760 Mbps (6 GHz) + 4320 Mbps (5 GHz) + 574 Mbps (2.4 GHz) for ultra-fast, lag-free connectivity.†
• Tri-Band Wi-Fi: Ensures optimized network traffic and minimal interference with dedicated frequency bands.
• 10G PoE++ Port: Unlocks the full potential of Wi-Fi 7 with ultra-fast wired backhaul and flexible deployment.
• 320 MHz Bandwidth: Supports ultra-wide channels for increased data throughput and improved network efficiency.‡
• Multi-Link Operation (MLO): Simultaneously transmits data across multiple frequency bands and channels, reducing latency and improving network stability.‡
• Auto Channel Selection & Power Adjustment: Enhances wireless performance while reducing interference.
• AI-Driven Optimization: Features Omada Mesh and AI Roaming for seamless wireless connectivity and expansion.△
• Advanced Security: Includes WPA3 encryption, captive portal authentication, rogue AP detection, and guest network support with up to 24 SSIDs.
• Centralized Cloud Management: Manage the network locally or remotely via Omada Cloud SDN.
• Ultra-Thin Design: Stylish, compact form factor measuring Φ220 mm × 32.5 mm, ideal for ceiling installations.

Technical Specifications

• Wi-Fi Standard: Wi-Fi 7 (802.11be), backward compatible with Wi-Fi 6/6E/5/4
• Frequency Bands:
  • 6 GHz: Up to 5760 Mbps
  • 5 GHz: Up to 4320 Mbps
  • 2.4 GHz: Up to 574 Mbps
• Ethernet Port: 1× 10G PoE++ Port (802.3bt)
• Security Features:
  • WPA3, WPA2-Enterprise
  • Captive portal authentication (SMS & Voucher login)△
  • Rogue AP detection
  • Up to 24 SSIDs for segmented network access
• Antenna Type: Internal high-gain antennas
• Management:
  • Omada Cloud SDN (Zero-Touch Provisioning, Intelligent Monitoring)
  • Auto Channel Selection & Power Adjustment
  • Mesh and AI Roaming△
• Dimensions: Φ220 mm × 32.5 mm
• Mounting: Ceiling-mount, ultra-thin design
• Power Supply: PoE++ (802.3bt)

Why Choose the EAP773?

• Enterprise-Grade Wi-Fi 7: Deliver next-generation speeds and enhanced reliability with Multi-Link Operation and 320 MHz Bandwidth.
• Optimized for High-Density Environments: Supports high-bandwidth applications such as cloud computing, HD video conferencing, and remote offices.
• Future-Proof Design: Features 4096-QAM, multi-RUs, and 10-bit symbol modulation for increased traffic capacity.
• Scalable & Centralized Management: Seamlessly integrates into Omada SDN for cloud-based or on-premises management.
• Enhanced Security & Guest Access: Protects business networks with WPA3 encryption, captive portal login, and rogue AP detection.
• Sleek, Space-Saving Design: Fits elegantly in offices, hotels, retail spaces, and educational institutions.

Omada Cloud SDN Integration

The EAP773 integrates seamlessly with Omada SDN, offering cloud-based network management with features such as:

• Zero-Touch Provisioning (ZTP) for effortless deployment.*
• Intelligent Monitoring to track network performance and security.
• Hybrid Cloud Management with hardware, software, or cloud-based controllers.
• AI-Powered Network Optimization for auto-adjusting channel settings and power levels.

Contact Us

For inquiries, product availability, or to place an order, contact us at:

Store Location:
SGCCTV Choicecycle, Sim Lim Square CCTV Specialist #02-81

Operating Hours:
11 AM – 8 PM

WhatsApp:
+65 98534404 (for stock inquiries before visiting)

Email:
enquiry@choicecycle.com.sg

Website:
https://sgcctv.biz

Conclusion

The EAP773 BE11000 Wi-Fi 7 Ceiling Mount Access Point is designed to redefine business networking with its ultra-fast tri-band speeds, AI-driven optimizations, enterprise-grade security, and centralized cloud management. Whether you’re upgrading your office network, enhancing retail connectivity, or deploying high-performance wireless coverage in a large venue, the EAP773 is the ultimate solution for future-proof, high-capacity networking. Contact us today to learn more or place an order!

† Maximum wireless signal rates are theoretical values derived from IEEE Standard 802.11 specifications. Actual performance may vary based on environmental conditions and network factors.

‡ Wi-Fi 7 features such as 320 MHz bandwidth, Multi-Link Operation (MLO), and 4K-QAM require compatible client devices.

△ Omada Mesh, AI Roaming, Captive Portal, and Cloud Access require an Omada SDN controller for full functionality. Please check the Omada user guide for configuration details.

• Zero-Touch Provisioning requires the Omada Cloud-Based Controller (subscription required).
