HANWHA TECHWIN WISENET QNO-6072R 2MP BULLET MOTORISED VARIFOCAL LEN Network IR Camera Korea Samsung Security System

Hanwha Vision Wisenet QNO-6072R 2MP IR Bullet Network Camera Singapore

Professional 2MP Varifocal IP Camera for Outdoor CCTV Security Systems

The Hanwha Vision Wisenet QNO-6072R is a professional 2MP H.265 IR bullet network camera designed for reliable commercial, industrial and outdoor CCTV surveillance.

It delivers 1920 × 1080 Full HD video, a 3.2–10mm 3.1× varifocal lens, up to 30fps, H.265/H.264 compression, infrared night vision, onboard microSD storage, PoE connectivity and rugged outdoor protection. The Q-series platform is positioned as a cost-effective professional surveillance solution for essential security applications. (Hanwha Vision)

Specification correction: The QNO-6072R/QNO-6072R1 uses a manual varifocal lens, not a motorised varifocal lens. For motorised zoom and remote-focus functionality, another Hanwha model should be selected. (Hanwha Vision)

Hanwha Vision was formerly known as Hanwha Techwin and has historical roots in Samsung Techwin’s security business. The current product brand is Hanwha Vision, while Wisenet remains widely recognised as its video-surveillance platform. (Hanwha Vision)

Key Features of Hanwha QNO-6072R

2MP Full HD Video

The QNO-6072R records at up to 1920 × 1080 Full HD resolution, providing clear surveillance images for general security monitoring.

It supports up to 30fps at 2MP using H.265 or H.264 compression. (Hanwha Vision)

Suitable applications include:

• Building entrances
• Warehouses
• Factories
• Offices
• Schools
• Retail shops
• Car parks
• Loading bays
• Perimeter areas
• Commercial properties

3.2–10mm Varifocal Lens

The camera features a 3.2–10mm, 3.1× manual varifocal lens.

This allows the installer to adjust the viewing angle during installation:

• Wider view for entrances, rooms and open areas
• Narrower view for gates, corridors and specific targets
• Approximate horizontal field of view from 109° to 33°

The lens includes a DC auto iris, but zoom and focus adjustment are manual rather than motorised. (Hanwha Vision)

Infrared Night Vision up to 30 Metres

Built-in infrared illumination allows the camera to continue monitoring after visible light becomes insufficient.

The QNO-6072R family provides an IR viewing distance of up to 30 metres, depending on the installation environment, target reflectivity and scene conditions. (Hanwha Vision)

Excellent Low-Light Performance

The camera is specified down to:

• 0.03 lux in colour
• 0 lux in black-and-white with IR switched on

This supports 24-hour surveillance across changing lighting conditions. (Hanwha Vision)

H.265, H.264 and MJPEG Compression

The QNO-6072R supports:

• H.265
• H.264
• MJPEG
• Multiple video streams

H.265 can reduce network bandwidth and storage requirements compared with older compression methods when used with a compatible NVR or video-management system. (Hanwha Vision)

WiseStream Video Compression

Hanwha’s WiseStream technology is designed to improve bandwidth and storage efficiency by reducing unnecessary video data while preserving important scene details.

This is particularly useful in multi-camera CCTV systems where storage capacity and network performance must be carefully managed.

Intelligent Camera Events

The camera supports essential video-event functions including:

• Motion detection
• Tampering detection
• Defocus detection
• Hallway view
• Lens distortion correction

These functions can assist with event-based recording and camera-health monitoring when configured with compatible software or an NVR. (Hanwha Vision)

Hallway View

Hallway View supports 90° or 270° image rotation, allowing the camera to use more of its image resolution when monitoring vertically shaped areas such as:

• Corridors
• Passageways
• Building entrances
• Narrow aisles
• Perimeter walkways

(Hanwha Vision)

Local MicroSD Recording

The camera supports microSD, microSDHC and microSDXC cards up to 128GB for onboard recording.

Local storage may be used for:

• Event recording
• Temporary standalone recording
• Network interruption backup
• Edge storage

A compatible high-endurance surveillance memory card is recommended. (Hanwha Vision)

PoE and 12V DC Power

The QNO-6072R can be powered using:

• Power over Ethernet
• 12V DC

PoE allows network communication and electrical power to travel through one Ethernet cable, simplifying installation when used with a compatible PoE switch or injector. (Hanwha Vision)

IP66 Outdoor Weather Protection

The camera carries an IP66 rating, protecting it against dust and strong water jets when properly installed.

This makes it suitable for sheltered and exposed outdoor applications in Singapore’s humid and rainy environment. (Hanwha Vision)

IK10 Vandal Resistance

The current QNO-6072R1 specification also lists IK10 impact resistance, providing additional protection against physical impact or tampering. Exact certification should be confirmed against the complete model revision supplied. (Hanwha Vision)

QNO-6072R vs QNO-6072R1

The QNO-6072R1 is a later revision of the QNO-6072R platform.

The current QNO-6072R1 listing confirms:

• 2MP resolution
• 3.2–10mm manual varifocal lens
• 30fps
• H.265/H.264/MJPEG
• 30m IR
• 128GB microSD
• IP66
• IK10
• PoE and 12V DC
• No built-in audio

Availability and exact specifications may vary by region and product revision. (Hanwha Vision)

Is the QNO-6072R a Samsung Camera?

The camera is not marketed today under the Samsung brand.

The manufacturer’s current name is Hanwha Vision, formerly Hanwha Techwin. Older customers may still refer to these products as Samsung Techwin or Samsung Wisenet because of the security division’s historical branding. (Hanwha Vision)

For accurate quotations and replacement projects, use the current manufacturer name:

Hanwha Vision Wisenet QNO-6072R

Ideal Applications in Singapore

The Hanwha QNO-6072R is suitable for:

• Factory CCTV
• Warehouse surveillance
• Commercial buildings
• Office entrances
• Retail shops
• Schools
• Clinics
• Car parks
• Loading bays
• Perimeter monitoring
• MCST properties
• Industrial facilities
• Existing Samsung Techwin system replacement
• Hanwha Wisenet CCTV upgrades

HANWHA TECHWIN WISENET QNO-6072R 2MP BULLET MOTORISED VARIFOCAL LEN Network IR Camera Korea Samsung Security System

CCTV Camera Repair and Replacement Singapore

When an existing Hanwha or Samsung Techwin camera becomes offline, avoid replacing it immediately without diagnosis.

A professional troubleshooting process should check:

PoE Power → Network Cable → Ethernet Link → IP Address → Password → Camera Stream → NVR/VMS

Common CCTV faults include:

• Camera offline
• No video
• Poor night vision
• Blurry image
• Damaged network cable
• Failed PoE switch port
• Incorrect IP address
• Password or authentication failure
• Water ingress
• Faulty infrared LEDs
• NVR compatibility problem
• Ageing camera hardware

SGCCTV provides Hanwha camera troubleshooting, network testing, repair assessment, replacement, configuration and CCTV system upgrading in Singapore.

SGCCTV – Hanwha Vision Security System Supplier Singapore

SGCCTV provides professional services for:

Hanwha Vision Cameras | Wisenet NVR | Samsung Techwin Replacement | IP CCTV Installation | PoE Network Testing | Camera Configuration | CCTV Repair | Camera Replacement | Preventive Maintenance | Technical Support

Contact SGCCTV Singapore

Website: sgcctv.biz
Email: enquiry@choicecycle.com.sg
WhatsApp: +65 98534404

HANWHA TECHWIN WISENET QNO-6072R 2MP BULLET MOTORISED VARIFOCAL LEN Network IR Camera Korea Samsung Security System

10 FAQ – Hanwha Wisenet QNO-6072R

1. What is the Hanwha QNO-6072R?

The QNO-6072R is a professional 2MP H.265 infrared bullet network camera with a varifocal lens, PoE, local microSD storage and outdoor weather protection. (Hanwha Vision)

2. What resolution does the camera support?

It supports a maximum resolution of 1920 × 1080 Full HD at up to 30fps. (Hanwha Vision)

3. Does the QNO-6072R have a motorised varifocal lens?

No. The specified 3.2–10mm lens is manually adjusted. Installers must set the zoom and focus at the camera during commissioning. (Hanwha Vision)

4. How far can the infrared night vision reach?

The built-in IR illumination provides a stated viewing distance of up to 30 metres, subject to scene and installation conditions. (Hanwha Vision)

5. Does it support H.265 compression?

Yes. It supports H.265, H.264 and MJPEG, together with multiple video streaming. (Hanwha Vision)

6. Can it record without an NVR?

Yes. The camera supports local microSD storage up to 128GB, although an NVR is generally recommended for centralised long-term recording. (Hanwha Vision)

7. Is the QNO-6072R suitable for outdoor installation?

Yes. It is rated IP66 for outdoor dust and water protection when properly installed. The newer QNO-6072R1 listing also specifies IK10 vandal resistance. (Hanwha Vision)

8. Does the camera support PoE?

Yes. It supports PoE and 12V DC power, allowing flexible installation. (Hanwha Vision)

9. Is Hanwha Vision the same as Samsung Techwin?

Hanwha Vision was formerly known as Hanwha Techwin. Many older users still associate Wisenet products with the earlier Samsung Techwin security business, but the current manufacturer brand is Hanwha Vision. (Hanwha Vision)

10. Where can I buy, repair or replace a QNO-6072R in Singapore?

Contact SGCCTV Singapore for Hanwha Vision cameras, Wisenet NVR systems, Samsung Techwin replacement, PoE testing, CCTV repair and installation.

WhatsApp: +65 98534404
Email: enquiry@choicecycle.com.sg
Website: sgcctv.biz

Recommended SEO Keywords

Hanwha QNO-6072R Singapore, Wisenet QNO-6072R, Hanwha Vision Bullet Camera, Hanwha Techwin CCTV Singapore, Samsung Techwin Camera Replacement, 2MP Network Camera Singapore, Varifocal Bullet Camera Singapore, Hanwha IR Camera, Wisenet IP Camera Singapore, 30m Night Vision Camera, H.265 CCTV Camera Singapore, IP66 Outdoor Camera, IK10 Bullet Camera, PoE Security Camera Singapore, Hanwha Camera Repair Singapore, Wisenet Camera Replacement, Samsung Security System Singapore, Korean CCTV Camera Singapore, Commercial CCTV Singapore, Industrial CCTV Singapore, SGCCTV Hanwha Supplier Singapore

HANWHA TECHWIN WISENET QNO-6072R 2MP BULLET MOTORISED VARIFOCAL LEN Network IR Camera Korea Samsung Security System

Professional Korea Samsung Security System for Singapore CCTV Installation & Maintenance

The Hanwha Techwin Wisenet QNO-6072R is a high-performance surveillance solution engineered by Hanwha Vision (formerly Samsung Techwin). Built for reliability, clarity, and intelligent monitoring, this 2MP bullet camera is ideal for commercial, industrial, and residential security systems across Singapore.

🔍 Key Features & Technical Advantages

🎯 Crystal Clear Full HD Surveillance

• 2 Megapixel (1920 × 1080) resolution
• Delivers sharp image quality for accurate identification
• Excellent performance in both day and night environments

🔧 Motorised Varifocal Lens (Remote Zoom & Focus)

• Adjustable focal length (approx. 3.2 ~ 10mm)
• Remote zoom and focus via NVR or software
• Reduces installation time—no manual lens adjustment required

🌙 Powerful Infrared Night Vision

• Built-in IR LEDs with up to 30m range
• True day/night (ICR) for clear low-light performance
• Ideal for 24/7 perimeter and outdoor surveillance

🧠 Smart Video Analytics

• Motion detection
• Tampering detection
• Defocus detection
• Optional intelligent event monitoring for enhanced security

💡 Wide Dynamic Range (WDR)

• Handles challenging lighting (backlight, glare, shadows)
• Ensures balanced exposure in entrances, carparks, and loading bays

🛡️ Built for Singapore Environment

🌧️ Weatherproof & Durable Design

• IP66-rated housing
• Suitable for outdoor use (rain, dust, humidity)
• Stable performance in tropical climate

🔌 Power over Ethernet (PoE)

• Single cable for power and data
• Cleaner installation, reduced cost

🏢 Ideal Applications

• Warehouse & factory surveillance
• Office buildings & commercial units
• Retail shops & shopping malls
• HDB / Condo perimeter security
• Carparks & loading bays

⚙️ Integration & Compatibility

• ONVIF compliant (works with most NVR systems)
• Seamless integration with Wisenet VMS
• Compatible with mobile viewing apps for remote monitoring

🚀 Benefits for Business Owners

• Reduce theft, vandalism, and unauthorized access
• Improve operational monitoring and safety
• Reliable long-term performance with Korean engineering
• Lower maintenance cost compared to low-grade cameras

📈 Why Choose Hanwha Wisenet (Samsung Security Line)?

• Trusted global brand with proven CCTV reliability
• Advanced image processing technology
• Strong cybersecurity standards
• Long product lifecycle support

🔧 Singapore CCTV Supply, Installation & Repair

Looking for professional installation or maintenance?
We provide full service for Hanwha / Samsung CCTV systems:

• Site survey & system design
• Installation & configuration
• Troubleshooting & repair
• Upgrade & replacement services

🌐 Website: https://sgcctv.biz
📧 Email: enquiry@choicecycle.com.sg
📱 WhatsApp: +65 98534404

🔎 SEO Keywords (Optimised)

Hanwha CCTV Singapore, Samsung Security Camera, Wisenet QNO-6072R review, 2MP bullet camera IR 30m, motorised varifocal CCTV Singapore, outdoor IP camera installation Singapore, CCTV repair Singapore, PoE security camera system, warehouse surveillance camera Singapore

HANWHA TECHWIN WISENET QNO-6072R 2MP BULLET MOTORISED VARIFOCAL LEN Network IR Camera Korea Samsung Security System

WISENET Samsung Dome Camera SCC-B5301P  || WISENET Samsung Box Camera SCC-B2391P ||
WISENET 2MP Varifocal Dome LNV-6072R ||
WISENET 2MP CCTV DOME QND6012R  || WISENET 2MP CCTV BULLET QNO-6012R ||
WISENET HANWHA DOME CAMERA XNV-6120R || WISENET HANWHA BULLET CAMERA XNO-6120R ||
WISENET 4MP CCTV BULLET QNO-7012R  || WISENET 4MP CCTV DOME QND-7012R  ||
WISENET HANWHA DOME CAMERA XNV-8081R || WISENET HANWHA DOME CAMERA QNV-8080R ||
WISENET HANWHA FISHEYE AI CAMERA XNF-9013RV || WISENET HANWHA FISHEYE CAMERA XNF-9010RV  ||
WISENET 2MP 32x PTZ QNP-6320  ||

WISENET Hybrid DVR HRD-442 HRX-434  ||  WISENET 4CH 8MP NVR XRN-420S  ||
WISENET 8CH 2HDD NVR XRN-815S  ||
WISENET 16CH 8HDD NVR XRN-1620B2  || WISENET 16CH 4HDD NVR XRN-1620SB1 || WISENET 16CH 20TB NVR XRN-1630S 16 PoE Ports ||
WISENET 32CH 8HDD NVR XRN-2011A ||  WISENET 32CH 8HDD NVR XRN-3210B2 ||
WISENET 64CH 8HDD NVR XRN-6410B2  ||

HANWHA TECHWIN WISENET QNO-6072R 2MP BULLET MOTORISED VARIFOCAL LEN Network IR Camera Korea Samsung Security System

1. Outdoor Surveillance: The camera’s weather-resistant design and IR illumination make it suitable for outdoor surveillance in environments such as parking lots, building perimeters, construction sites, and public spaces.
2. Indoor Surveillance: In indoor environments such as offices, warehouses, retail stores, and manufacturing facilities, the camera can monitor entrances, hallways, production areas, and storage spaces to enhance security and prevent theft or vandalism.
3. Residential Areas: The camera can be installed in residential settings such as homes, apartment complexes, and gated communities to monitor entryways, driveways, and common areas, providing homeowners with peace of mind and enhancing home security.
4. Educational Institutions: Schools, colleges, and universities can use the camera to monitor campuses, classrooms, hallways, and parking lots to ensure the safety of students, faculty, and staff and prevent unauthorized access or suspicious activities.
5. Healthcare Facilities: Hospitals, clinics, and medical centers can benefit from the camera’s surveillance capabilities to monitor entrances, waiting areas, corridors, and parking lots, enhancing security and ensuring the safety of patients, visitors, and staff.
6. Retail Environments: The camera can be deployed in retail environments such as malls, supermarkets, and shops to monitor entrances, aisles, cash registers, and storage areas, helping to prevent shoplifting, employee theft, and other security incidents.
7. Transportation Hubs: Airports, train stations, bus terminals, and seaports can use the camera to monitor terminals, platforms, baggage claim areas, and parking lots, enhancing security and ensuring the safety of passengers and staff.
8. Industrial Facilities: Factories, warehouses, and manufacturing plants can benefit from the camera’s surveillance capabilities to monitor production lines, storage areas, loading docks, and perimeter fences, preventing theft, vandalism, and unauthorized access.
9. Public Spaces: The camera can be deployed in public spaces such as parks, stadiums, convention centers, and city centers to monitor crowds, deter criminal activities, and enhance public safety during events or gatherings.

Overall, the Hanwha Techwin Wisenet LNV-6070R camera is versatile and can be effectively used in a wide range of environment settings to provide reliable surveillance and security monitoring.
